1. Equipped with a picosecond laser, working in combination with Cutting II as a high- value alternative to femtosecond systems.
2 .Enables stable cold machining of various materials and high-precision finishing of PCD profile tools.
3 . Cutting II for roughing + Comfort II for finishing delivers performance comparable to femtosecond systems, without product limitations。
4 . Specially developed for 3C industry appearance tools, offering precise and efficient solutions.
Equipment parameters
|
Machine Model |
FUTURE comfort series LASER -C380 |
|
Machine tool linear axis Trevel |
X*Y*Z：380*380*380mm |
|
Rotating Range |
A-axis: 0-360 °, B-axis -35°，+92 ° |
|
Type of laser |
1064 - picosecond laser |
|
Main Application |
ultra-hard tools cutting edge process；tool flute making； Integral Ultra-hard tools |
|
Linear Axis accuracy |
Repetition: 0.003mm Positioning: ± 0.003mm |
|
A/B Rotating accuracy |
Repeat: 3 arc seconds Positioning: ± 3 arc seconds |
|
Maximum tool weight |
10 kg |
|
Maximum tool diameter and length |
Diameter: 180MM, maximum length:260MM |
|
Dimensions |
L: 2280 * W2950 * H2235mm |
|
weight |
4.8 tons |
|
Tool (workpiece) mounting interface |
HSK-A63 interface |
External dimensions Installation conditions
|
Power requirements
|
AC220V ± 10% 2 phase 5KW CE60A or above |
Installation environment |
Please place the machine on the concrete floor that can bear the weight of the machine, without vibration and impact, within the temperature range of 22 °~26 ° C, humidity<50% RH (no condensation), and the environment is free of oil mist and dust. |
|
Air source requirements |
＞0.55MPa |
Grounding construction |
It is recommended to follow the Class C regulations in the electrical equipment standard. Please construct separately from other machines |
